Different series of Smart Vision lenses
Smart Vision industrial lenses support a focus range from ultra-short working distance (starting from 100mm or 250mm) to infinity, and provide a variety of focal lengths from 3.5mm to 75mm, suitable for high-resolution cameras from 20 million to 25 million pixels, and the maximum target surface supports 1.1" or 4/3".
Product Name resolution Pixel size Lens mount Aperture range Focal Length Distortion (%) Magnification Working Distance
ZX-SF1628W 12MP - C-mount 2.8-16 16mm ＜0.33 0.25-0.3 52-546
ZX-SF2528W 12MP - C-mount 2.8-25 25mm ＜0.07 18.5 65-260.4
ZX-SF3528W 12MP - C-mount 2.8-16 35mm ＜0.05 0.70-0.25 59-150
ZX-SF5028W 12MP - C-mount 2.8-16 50mm ＜0.05 0.8-0.5 95.4-132.4
ZX-SF7538W 12MP - C-mount 3.8-16 75mm ＜0.05 0.38-0.18 257-471
ZX-5M014200 5MP 2/3″ C-Mount F6.5 - ＜0.02 0.14 200mm
ZX-5M15110 5MP 2/3″ C-Mount F9 - ＜0.05 1.5 110mm
ZX-5M20110 5MP 2/3″ C-Mount F12 - ＜0.05 2 110mm
ZX-5M022200 5MP 2/3″ C-Mount F6 - ＜0.02 0.22 200mm
ZX-5M0265178 5MP 2/3″ C-Mount F6 - ＜0.03 0.265 178mm
ZX-1CM03200 20MP 1.1″ C-Mount F6 - ＜0.02 0.3 200mm
ZX-1CM04178 20MP 1.2″ C-Mount - - ＜0.03 0.4 178mm
ZX-1CM07110 20MP 1.2″ C-Mount F7.5 - ＜0.05 0.7 110mm
ZX-1CM10110 20MP 1.1″ C-Mount F7 - ＜0.05 1 110mm
ZX-1CM052110 20MP 1.1″ C-mount F6 - ＜0.05 0.52 110mm
ZX-1CM025230 20MP 1.1″ C-Mount F6 - ＜0.02 0.25 230mm
ZX-SF1214S 5MP 1″ C-mount 1.4-16 12mm ±1.8 - 0.1m-∞
ZX-SF1614S 5MP 1″ C-mount 1.4-16 16mm ±0.2 - 0.1m-∞
ZX-SF2514S 5MP 1″ C-mount 1.4-16 25mm ±0.1 - 0.1m-∞
ZX-SF3514S 5MP 1″ C-mount 1.4-16 35mm ±0.1 - 0.15m-∞
