ZX-SFM032-182
Lomosen
12MP
2/3″
F6
＜0.01
0.32X
C-mount
182mm±3%
| Quantity: | |
|---|---|
Product Introduction
The ZX-SFM032-182 fixed-magnification lens has a magnification of 0.32X, providing stable and clear imaging over a wide field of view, making it suitable for precision inspection applications at low to medium magnification. The lens is designed with a working distance of 182 mm, ensuring image quality while providing ample space for on-site installation and light source placement, enhancing the overall adaptability and flexibility of the system.
Simultaneously, this lens features a depth of field of 6.5 mm, maintaining good image sharpness even when the measured object has a certain height difference or slight positional change, reducing the frequency of focusing. Its overall performance is stable, making it suitable for dimensional measurement, appearance inspection, and continuous inspection applications in automated production lines.
